Hygienic Enclosed Safety Isolators 63A - 80A

Hygienic BKP Series

iHATHOR enclosed hygienic safety isolators available in a wide range of currents from 63A up 80A. Is ideal for food handling facilities (clean rooms) or manufacturing processes which requires a high degree of hygiene. The European Hygienic Engineering & Design Group (EHEDG) has certified the compatibility of the safety switches with food processing systems.

63A-80A iHATHOR Hygienic Switch Disconnector · iHATHORiHATHOR
63A-80A iHATHOR Hygienic Switch Disconnector · iHATHORiHATHOR

This product has the following certificates

  • Logo CE · iHATHOR
  • Logo IP66 · iHATHOR
  • Logo UL NEMA 12 · iHATHOR
  • Logo UL NEMA 3R · iHATHOR
  • Logo UL NEMA 4X · iHATHOR
  • Logo 10 year anti-corrosion · iHATHOR

Description

iHATHOR enclosed hygienic safety isolators available in a wide range of currents from 63A up 80A. Is ideal for food handling facilities (clean rooms) or manufacturing processes which requires a high degree of hygiene. The European Hygienic Engineering & Design Group (EHEDG) has certified the compatibility of the safety switches with food processing systems.

iHATHOR Hygienic Series is a full line of safety and isolation switches with integral sloping roof offers additional protection and leads to self-draining of liquids, specially designed for food industry. No openings, hinges where bacteria could lie, moreover the inclination of the roof prevents objects being placed on the surface and our vertical electro polished finish helps repel liquids and prevent virus and bacteria building up on the surface.



Hygienic Switch Disconnector 63A - 80A iHATHOR

Discover the advantages

With electro-polished finish that helps dispel liquids and waterproof seal that prevents dirt and bacteria deposits.
The monobloc manufacture gives total sealing and maximum resistance.
No openings where bacteria could lie.
Ready for installation
Compact design.
Possibilities in custom housing design.
Versatility.
Fast delivery time.
Custom designs available.
Quantity discount.

Regulations

  • Machinery Directive 2006/42/EC (previously 89/37/EC) Food machinery and cosmetic or pharmaceutic production.
  • EHEDG Guideline Hygienic Design doc.13 machinery for open processes.
  • DIN EN 1672-2:2006 for food industry machinery.
  • IEC/EN 60947-3
  • IP66 Norm IEC EN 62208 and EN 60529.
  • Maximum IK10 resistance Norm IEC62208 and IEC 62262.
  • UE Directive of low voltage 2014/35/UE.
  • Materials intended to come into contact with food, CE 1935/2004.
  • Offhore, maritime grade IP66.
  • UL Standard(s) Safety: UL508A- Industrial Control Panels, CSA C22.2 No.14- Industrial Control Equipment.

Applications

Hygienic safety switches installation where require special vigilance in compliance with their demanding regulations in places that require a high level of hygiene such as medical machinery, food industry, clean rooms, pharmaceutical industry,...
iHATHOR hygienic safety switches are reliable and provide safety to your property and your personnel in addition to providing:

  • Protection against overcurrent.
  • Protection against circuit overloads.
  • Protection against short circuiting.
  • Protection against heat-generated damage.

Safety switches are designed to interrupt the power in the event of a single fault in the circuit. Custom solutions projects for small and large series. iHATHOR is certified UL, Nema 4x.

Custom Made Solutions
We offer multiple solutions

Hygienic Enclosed Safety Isolators 63A - 80A · iHATHOR
Do you need solutions?
2021 product catalogues
  • The most standard products are presented, options are available upon request.
  • Option multiple of switch, nº of poles, current, aux. contacts,...
  • Drills in base your needs.
  • Option of different supports.
  • Option of manufactured in different materials: stainless steel AISI 316L (enclosure maritime grade) or painted galvanized steel finish in RAL 7035 or another color.
  • Design on IP67 or IP68 box.
  • Possibility of Atex load switch.
Customers also bought:
Switch Disconnector 20A - 25A - 40A · iHATHORiHATHOR
iHATHOR disconnectors available in 20A, 25A and 40A currents. BKP Series has been designed...
Safety Switch 63A - 80A · iHATHORiHATHOR
iHATHOR safety switch available in a wide range of currents from 63A and 80A. BKP Series has been...
Switch Disconnector 100A - 125A · iHATHORiHATHOR
iHATHOR switch disconnectors available in a wide range of currents from 100A and 125A. BKP Series...
Ex Enclosed Safety Switch · iHATHORiHATHOR
Atex e IECEx enclosed isolation switch with lid secured quickly by quarter turn of captive screw,...
Ex Enclosed Switch Disconnector · iHATHORiHATHOR
Ex enclosed switch disconnector the enclosure has a hinged door, with door lock, made in stainless...
Ex GRP Switch Disconnector · iHATHORiHATHOR
The GRP Enclosed Switch Disconnector are made of glass fibre reinforced polyester “Ex e”,...
Hygienic Enclosed Safety Isolators 20A - 25A - 40A · iHATHORiHATHOR
iHATHOR enclosed hygienic safety isolators available in a wide range of currents from 20A up 40A. Is...
Hygienic Enclosed Safety Isolators 63A - 80A · iHATHOR

Sketches
